How Pi Works: A Developer's Map to Customization

I used Cursor with auto models and never thought about customization. Then I discovered Pi's extension system. Here's the architecture diagram I wish I had on day one.

Posted Oct 7, 2026

By Boyu Li

13 min read

How Pi Works: A Developer's Map to Customization

Introduction

I used to depend on Cursor with auto models. Type a prompt, get code, move on.

Then I started using Pi. Same surface, but different. Pi suggested tools I didn’t ask for. My context survived sessions that should have been forgotten. Extensions seemed to know what I was doing before I did.

I wanted to understand how it all worked — where each piece fits and when I could customize it.

This post is the map I built.

Part 1: How Pi Works (Without Extensions)

Let’s start with pure Pi — no extensions, no customizations. Just the core agent doing its job.

The Request Lifecycle

Every time I talk to Pi, my request flows through seven stages:

┌─────────────────────────────────────────────────────────────┐
│  1. You type a prompt                                       │
└─────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────┐
│  2. Pi gathers context                                      │
│     • AGENTS.md, settings, session history                  │
└─────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────┐
│  3. Pi builds the request                                   │
│     • System prompt + tools + context                       │
└─────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────┐
│  4. Provider sends to LLM                                   │
│     • OpenAI, Anthropic, etc.                               │
└─────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────┐
│  5. LLM responds                                            │
│     • Text and/or tool calls                                │
└─────────────────────────────────────────────────────────────┘
         │
         ▼
    ┌────┴────┐
    │  Tool   │
    │  calls? │
    └────┬────┘
     Yes │     No
         │     │
         ▼     │
┌──────────────────┐
│  6. Pi executes  │
│     tools        │
│  • read, edit,   │
│    bash, etc.    │
└──────────────────┘
         │
         ▼
┌──────────────────┐
│  7. Record       │
│     results      │
└──────────────────┘
         │
         ▼
    ┌────┴────┐
    │  More   │
    │  turns? │
    └────┬────┘
     Yes │     No
         │     │
         ▼     ▼
    [Back to   ┌──────────────────┐
     step 3]   │  8. Save to      │
               │     session      │
               │  • JSONL file    │
               └──────────────────┘

Each box is a place where I can customize behavior. But first, let’s see it in action.

A Concrete Example

You’re building an Express app. You ask Pi: “Add a hello world endpoint”

Here’s what happens:

sequenceDiagram
    participant You
    participant Pi
    participant Context
    participant Provider
    participant Tools
    participant Session

    You->>Pi: "Add a hello world endpoint"
    Pi->>Context: Load AGENTS.md, .pi/settings.json
    Context-->>Pi: Project rules + settings
    Pi->>Provider: System prompt + context + tools
    Provider-->>Pi: "I'll read your app structure first"
    Pi->>Tools: read("src/app.ts")
    Tools-->>Pi: File contents
    Pi->>Provider: Tool result
    Provider-->>Pi: "Now I'll add the endpoint"
    Pi->>Tools: edit("src/app.ts", add route)
    Tools-->>Pi: File updated
    Pi->>Tools: bash("npm test")
    Tools-->>Pi: Tests pass
    Pi->>Session: Record all entries
    Session-->>Pi: Saved
    Pi-->>You: "Done! Added GET /hello endpoint"

Step by step:

Context: Pi loads my project’s AGENTS.md and .pi/settings.json — these tell Pi about my conventions
Provider: The LLM decides to read my app first (smart move)
Tools: Pi executes three calls in sequence — read, edit, test
Session: Everything is recorded so Pi remembers this work next time

That’s pure Pi. The model decided the sequence, Pi executed the tools, and the session was saved. No magic, no extensions.

Part 2: Where Extensions Plug In

Now let’s talk about extensions.

What Are Extensions?

Extensions are TypeScript modules that hook into Pi’s lifecycle at specific points. They can:

Add custom tools
Intercept tool calls before or after they execute
Transform context
Register commands and shortcuts

They run inside Pi’s process — not as external services, but as native code with deep access to the agent’s internals.

Meet `context-mode`

context-mode is an extension I use daily. It does three things:

Tool routing: Suggests which tool to use for different tasks
Context savings: Compresses large outputs to save tokens
Session continuity: Preserves context across compactions

Without context-mode, Pi works fine. With it, Pi becomes more efficient and my context persists better across long sessions.

Meet `pi-memory`

pi-memory is another popular extension (40K+ monthly downloads as of Oct 7, 2026). It gives Pi a persistent memory across sessions:

Long-term memory: Stores decisions, preferences, and facts in MEMORY.md
Daily logs: Automatically records what happened each day
Scratchpad: A checklist of things to come back to
Semantic search: With optional qmd, I can search across all memories

Example:

# Session 1
me ▸ I always use pnpm in this repo, never npm. Remember that.
pi  ▸ Got it — saved to long-term memory.

# …days later, brand new session…
me  add prettier as a dev dependency
pi   pnpm add -D prettier
      (recalled my package-manager preference — no reminder needed)

Both extensions use the same core mechanism: hooks into Pi’s lifecycle.

The Extension Hook Points

Extensions plug into Pi at specific moments. Here’s where context-mode and pi-memory hook in:

Session Lifecycle:

  [Session Starts]
       │
       ├──→ context-mode: injects routing instructions
       └──→ pi-memory: loads MEMORY.md into context
       │
  [User sends message]
       │
  [Tool call about to execute]
       │
       └──→ context-mode: suggests better tools (PreToolUse)
       │
  [Tool executes]
       │
  [Tool completes]
       │
       ├──→ context-mode: captures events (PostToolUse)
       └──→ pi-memory: writes to daily log
       │
  [Results recorded]
       │
  {Context too long?}
       │
       ├──→ Yes → [sessionBeforeCompact hook]
       │              ├──→ context-mode: saves session state
       │              └──→ pi-memory: creates handoff entry
       │
       └──→ No → [Session continues]
       │
  [Session ends]
       │
       └──→ pi-memory: writes exit summary

Key insight: Both extensions use the same hook system, but at different points. context-mode focuses on tool execution (pre/post hooks), while pi-memory focuses on session boundaries (start/end/compaction).

How They Store Data

context-mode Storage:
  ~/.context-mode/content/
  ├── sessions.db          # Session events (SQLite)
  ├── content.db           # Indexed web pages, docs (SQLite)
  └── stats.db             # Usage statistics (SQLite)

pi-memory Storage:
  ~/.pi/agent/memory/
  ├── MEMORY.md            # Long-term facts, decisions
  ├── SCRATCHPAD.md        # Todo checklist
  └── daily/
      ├── 2026-10-07.md    # Today's log
      └── 2026-10-06.md    # Yesterday's log

Why it matters: context-mode uses SQLite for fast indexing and search. pi-memory uses plain Markdown so I can cat, git commit, or edit the files directly. Both approaches have trade-offs.

Part 2.5: The Hook System

Hooks are callback functions that Pi calls at specific moments. Extensions register these to intercept or augment Pi’s behavior.

The Five Hook Points

sessionStart — Inject instructions, load context
preToolUse — Suggest better tools, deny dangerous commands
postToolUse — Capture events, update state
sessionBeforeCompact — Save state, create handoff
exitSummary — Write summary, cleanup

How Extensions Register Hooks


pi.on('sessionStart', async (event, ctx) => {
  return { instructions: 'Use ctx_execute for large outputs' };
});

pi.on('preToolUse', async (event, ctx) => {
  const { toolName, toolInput } = event;
  if (toolName === 'read' && toolInput.path.endsWith('.log')) {
    return { redirect: 'ctx_execute_file', newInput: toolInput };
  }
});

This is what makes Pi truly extensible — not just new tools, but the ability to modify behavior at every stage.

Part 3: The Same Example, With context-mode

Let’s revisit the hello world example with context-mode installed.

Request 1: “Add a hello world endpoint”

sequenceDiagram
    participant You
    participant Pi
    participant context-mode
    participant Context
    participant Provider
    participant Tools
    participant Session

    You->>Pi: "Add a hello world endpoint"
    Pi->>context-mode: SessionStart hook fires
    context-mode-->>Pi: Inject routing instructions
    Pi->>Context: Load AGENTS.md, .pi/settings.json
    Context-->>Pi: Project rules + settings
    Pi->>Provider: System prompt + context + tools + routing
    Provider-->>Pi: "I'll read your app structure first"
    Pi->>Tools: read("src/app.ts")
    Tools-->>Pi: File contents
    Pi->>Provider: Tool result
    Provider-->>Pi: "Now I'll add the endpoint"
    Pi->>Tools: edit("src/app.ts", add route)
    Tools-->>Pi: File updated
    Pi->>context-mode: PostToolUse hook fires
    context-mode-->>Pi: Captures file edit event
    Pi->>Tools: bash("npm test")
    Tools-->>Pi: Tests pass
    Pi->>context-mode: PostToolUse hook fires
    context-mode-->>Pi: Captures test results
    Pi->>Session: Record all entries
    Session-->>Pi: Saved
    Pi-->>You: "Done! Added GET /hello endpoint"

What changed: context-mode injected routing instructions at the start and captured events after each tool call. The output looks the same, but context-mode is silently working in the background.

Request 2: “Now extend it to accept a name parameter”

On the follow-up request, context-mode becomes more active:

sequenceDiagram
    participant You
    participant Pi
    participant context-mode
    participant Context
    participant Provider
    participant Tools
    participant Session

    You->>Pi: "Extend it to accept a name parameter"
    Pi->>Context: Load previous session + AGENTS.md
    Context-->>Pi: "Last turn: added GET /hello"
    Pi->>Provider: Full context + routing rules
    Provider-->>Pi: "I'll read the endpoint, then modify it"
    Pi->>Tools: read("src/app.ts")
    Tools-->>Pi: File contents (large output)
    Pi->>context-mode: PreToolUse hook fires
    context-mode-->>Pi: "Suggest ctx_execute_file for large outputs"
    Pi->>Provider: Tool result
    Provider-->>Pi: "Now I'll add validation"
    Pi->>Tools: edit("src/app.ts", add validation)
    Tools-->>Pi: File updated
    Pi->>context-mode: PostToolUse hook fires
    context-mode-->>Pi: Captures file edit event
    Pi->>Tools: bash("npm test")
    Tools-->>Pi: Tests pass
    Pi->>context-mode: PostToolUse hook fires
    context-mode-->>Pi: Captures test results
    Pi->>Session: Record entries
    Pi->>context-mode: sessionBeforeCompact hook (if needed)
    context-mode-->>Pi: Saves session state
    Session-->>Pi: Saved with continuity
    Pi-->>You: "Done! Added name parameter with validation"

What changed in the follow-up:

Context Assembly: Pi loaded the previous session — it remembered the first request
PreToolUse hook: When read returned a large file, context-mode suggested using ctx_execute_file
PostToolUse hooks: Captured every tool event
sessionBeforeCompact hook: If context gets too long, context-mode saves state for continuity

The pattern: In Request 1, context-mode was mostly silent. In Request 2, it actively participated — providing routing guidance, suggesting better tools, and ensuring continuity.

Part 4: The Customization Points

Now that I’ve seen Pi in action, here’s where I can customize each stage:

┌─────────────────────────────────────────────────────────────────┐
│  Stage 1: User Input                                            │
│  Customize: Prompt templates                                    │
└─────────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────────┐
│  Stage 2: Context Assembly                                      │
│  Customize: AGENTS.md, extensions, skills                       │
└─────────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────────┐
│  Stage 3: Model Request                                         │
│  Customize: Provider, settings                                  │
└─────────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────────┐
│  Stage 4: Provider & Response                                   │
│  Customize: Custom providers                                    │
└─────────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────────┐
│  Stage 5: Tool Execution  ⚡⚡                                    │
│  Customize: Custom tools, permissions, hooks                    │
│  ← Most customization happens here!                             │
└─────────────────────────────────────────────────────────────────┘
         │
         ▼
┌─────────────────────────────────────────────────────────────────┐
│  Stage 6: Session Storage  ⚡                                    │
│  Customize: Branching, compaction hooks                         │
└─────────────────────────────────────────────────────────────────┘

Color guide:

Stages 1-2 (green): What Pi knows
Stages 3-4 (blue): Which model Pi uses
Stage 5 (yellow): Where most customization happens — tools, permissions, and hooks
Stage 6 (red): How Pi remembers

Let me walk through each stage:

Stage 1: User Input

My editor input goes through prompt templates and becomes a user message.

Customize with: Prompt templates

Stage 2: Context Assembly

Pi builds the system prompt from its base instructions and discovered context files.

Customize with:

Context files: Drop AGENTS.md, CLAUDE.md, or CONTEXT.md in my project root
Extensions: Can add instructions or transform context
Skills: Provide on-demand instructions

context-mode hooks here: sessionStart hook injects routing instructions

Tip: Drop a .pi/AGENTS.md file in my project and Pi will automatically include it in every request.

Stage 3: Model Request

Pi builds a model request and sends it through the selected provider.

Customize with:

Provider selection: Which LLM provider to use
Model overrides: Per-model token budgets
Settings: Two locations:
- Global: ~/.pi/agent/settings.json
- Project-level: <project>/.pi/settings.json

My preference: Project-wise settings so configurations don’t leak between projects.

Stage 4: Provider & Response

The provider streams an assistant response.

Customize with: Custom providers (for non-standard LLMs)

Stage 5: Tool Execution ⚡

Pi executes each tool call and records the results.

Customize with:

Custom tools (via extensions)
Tool permissions
Event handlers: sessionStart, preToolUse, postToolUse

context-mode hooks here:

PreToolUse Hook

Intercepts tool calls before execution. Injects routing guidance like “Wrap large external-MCP payloads in ctx_execute”.

PostToolUse Hook

Captures tool events after execution: file edits, git operations, errors, tasks.

Tool Hierarchy

context-mode registers 11 MCP tools:

ctx_batch_execute (highest)
  ─ ctx_execute
        ── ctx_execute_file
              ── ctx_search (lowest)

My daily routing:

Read/edit files → ctx_execute_file
Multi-command research → ctx_batch_execute
Web pages → ctx_fetch_and_index then ctx_search
Index docs → ctx_index

Stage 6: Session Storage ⚡

Persistent sessions are JSONL files. Compaction inserts a summary entry that replaces older messages.

Customize with:

Branching: /tree, /fork, /clone
Compaction hooks: sessionBeforeCompact

context-mode hooks here: sessionBeforeCompact captures session state, enabling continuity

Tip: When Pi compacts, context-mode saves the session state so I can restore it later.

Part 5: The Customization Spectrum

Customization comes in three levels:

graph LR
    A["Quick Wins"] --> B["Deeper Integration"]
    B --> C["Full Control"]

    A1["Context Files<br/>(AGENTS.md)"] --> A
    A2["Settings<br/>(.pi/settings.json)"] --> A
    A3["Prompt Templates"] --> A

    B1["Skills<br/>(on-demand instructions)"] --> B
    B2["MCP Servers<br/>(external tools)"] --> B
    B3["context-mode<br/>(extension + hooks)"] --> B

    C1["Custom Extensions<br/>(TypeScript)"] --> C
    C2["Custom Providers<br/>(model routing)"] --> C
    C3["Custom Tools<br/>(native integration)"] --> C

    style A fill:#90EE90
    style B fill:#FFD700
    style C fill:#FF6B6B

My journey: Context files first (5 minutes), then context-mode (10 minutes). I haven’t written custom extensions yet, but now I know where to plug in.

Practical Examples

Goal	Solution	Extension	Level
Add custom instructions per project	Drop `AGENTS.md` in project root	None	Quick Win
Set project-specific settings	Create `<project>/.pi/settings.json`	None	Quick Win
Remember preferences across sessions	`memory_write` tool	pi-memory	Quick Win
Intercept tool calls	`sessionStart`/`preToolUse`/`postToolUse` hooks	context-mode	Deeper
Change how compaction works	`sessionBeforeCompact` hook	context-mode, pi-memory	Deeper
Fetch docs once, search many times	`ctx_fetch_and_index` then `ctx_search`	context-mode	Deeper
Search across all memories	`memory_search` (requires qmd)	pi-memory	Deeper
Add a new tool	Extension with tool registration	Custom	Full Control
Custom model routing	Custom provider extension	Custom	Full Control

Conclusion

Pi is a programmable agent, not just a chat interface. The lifecycle diagram is my map — every box is a customization point.

Where I started:

Dropped an AGENTS.md file in my project (5 minutes)
Installed context-mode for tool routing and session continuity (10 minutes)
Explored the settings hierarchy (~/.pi vs <project>/.pi/) (15 minutes)

The difference between using a tool and mastering it is understanding how it works. Now I have the map.

How Pi Works: A Developer's Map to Customization

Introduction

Part 1: How Pi Works (Without Extensions)

The Request Lifecycle

A Concrete Example

Part 2: Where Extensions Plug In

What Are Extensions?

Meet `context-mode`

Meet `pi-memory`

The Extension Hook Points

How They Store Data

Part 2.5: The Hook System

The Five Hook Points

How Extensions Register Hooks

Part 3: The Same Example, With context-mode

Request 1: “Add a hello world endpoint”

Request 2: “Now extend it to accept a name parameter”

Part 4: The Customization Points

Stage 1: User Input

Stage 2: Context Assembly

Stage 3: Model Request

Stage 4: Provider & Response

Stage 5: Tool Execution ⚡

PreToolUse Hook

PostToolUse Hook

Tool Hierarchy

Stage 6: Session Storage ⚡

Part 5: The Customization Spectrum

Practical Examples

Conclusion

Further Reading

Trending Tags

Introduction

Part 1: How Pi Works (Without Extensions)

The Request Lifecycle

A Concrete Example

Part 2: Where Extensions Plug In

What Are Extensions?

Meet context-mode

Meet pi-memory

The Extension Hook Points

How They Store Data

Part 2.5: The Hook System

The Five Hook Points

How Extensions Register Hooks

Part 3: The Same Example, With context-mode

Request 1: “Add a hello world endpoint”

Request 2: “Now extend it to accept a name parameter”

Part 4: The Customization Points

Stage 1: User Input

Stage 2: Context Assembly

Stage 3: Model Request

Stage 4: Provider & Response

Stage 5: Tool Execution ⚡

PreToolUse Hook

PostToolUse Hook

Tool Hierarchy

Stage 6: Session Storage ⚡

Part 5: The Customization Spectrum

Practical Examples

Conclusion

Further Reading

Trending Tags

Meet `context-mode`

Meet `pi-memory`
